GAV terracotta panels are perfect for renovation projects on buildings with a ventilated facade. GAV ceramic pieces are known for their unique 300×600 format which allows a balance between performance and adaptation with longitudinal multi-anchoring. Ceramic panels with a terracotta finish are quite suitable for renovating facades on buildings such as: The tones of GAV ceramic pieces are available in white, red, brown and gray terracotta colors. Terracotta. They stand out due to the intensity of the smooth, solid colors in the ceramic pieces such as white, red, brown and gray. • Horizontal joint overlap • Hidden anchoring • Easily adjustable longitudinal multi-anchoring GAV ceramic pieces for ventilated facades weigh 36 kg/m2, are 19 mm thick and are available in this format (nominal/real): Width of GAV ceramic pieces: 300/305 Length: 600/592 FAVEKER® ceramic tiles for ventilated facades can be installed over light fixing systems to optimize the costs of the underlying structure all while emphasizing a linear design that absorbs vibrations. In addition to being easy to assemble, the best thing about FAVEKER® pieces is that they’re compatible with several of these systems meaning the customization possibilities for a ventilated facade are endless. The most appropriate anchoring system for GAV pieces is the FTS 502A fixing system. GAV
terracotta panels For ventilated facade building renovations
On what types of buildings can GAV terracotta panels be installed?
Range of colors on GAV ceramic pieces with a terracotta finish
Characteristics of GAV ceramic pieces
Format and dimensions of GAV ceramic pieces
Fixing systems and installation of GAV panels for ventilated facades
Which fixing systems are most appropriate for GAV ceramic pieces?
Characteristics table for GAV ceramic models
STANDARD TEST
DECLARED VALUE
Weight
36 (kg/m2)
EN standard
IS0 13006 UNE-EN 14411
Water absorption
UNE EN 10545-3
3 < Ev < = 6 %
Moisture expansion
UNE EN 10545-8
<0.1mm/m
Thermal expansion
UNE EN 10545-10
<6 μm/(m°C)
Frost resistance
UNE EN 10545-12
no frost
Stain resistance
UNE EN 10545-14
mínimo
Breaking strength (break module)
UNE EN 10545-4
>17 MPa
Breaking strength
UNE EN 10545-4
>1200 N
Colour tolerance
UNE EN 10545-13
ΔE < 1
Dimensional Tolerance: side straightness
UNE EN 10545-2
±0,2%
Dimensional Tolerance: orthogonality
UNE EN 10545-2
±1%
Dimensional Tolerance: side curvature
UNE EN 10545-2
±0,5%
Dimensional Tolerance: length / height
UNE EN 10545-2
±1mm / ±2mm
Thickness tolerance
UNE EN 10545-2
19 mm±10%
Reaction to fire
EN 13501
A1/B-s1, d0 *
